Index: PB-0FPO18-350
Bottom mounting guide P2O L=350, MODERN SLIDE, plate 18 mm
Product description
The push to open bottom mounting guide, available in eight dimensional variants. Made of steel coated with zinc coating to protect against corrosion. It uses slide-on mounting technology. Drawers equipped with a push to open mechanism open when the front is lightly pressed, facilitating everyday use in rooms where we need convenient access to products without the use of handles. The full extension allows access to the entire depth of the drawer, and vertical adjustment without tools will facilitate the assembly process and the appropriate adjustment of the drawer slide. The product will find its universal application for drawers with side walls made of material with a thickness of 16 - 19 mm. In addition, the durability of the product is certified for 60,000 cycles and withstands loads of up to 25 kg.
load up to 25 kg;
proven, certified product durability for 60,000 cycles;
Universal use for drawers with side walls made of
with a thickness of 16 – 19 mm;full extension;
push to open;
slip-on mounting;
Vertical adjustment without tools in the range:
0-3mm
possibility of using the PB-D-P2OSTAB stabilizer.
